Copperhead Conductors installed on insulators, combine the advantages of high conductivity, low voltage drop and great mechanical strength with a very high life expectancy - from 200 to 3000 amps.
Recommended for: Cat. 1a |
|
Uni-Pole Insulated Conductors are single phase, insulated conductors, for indoor and outdoor installations. Compact hangers allow space saving arrangements - from 10 to 1000 amps.
Recommended for: Cat. 2a, 2b & 2c |
|
Powerail system (with metal housing) is a compact multiple conductor system with a steel or aluminium housing - 4 to 11 conductors with a capacity from 60 to 300 amps.
Recommended for: Cat. 3a & 3b |
 |
Powerail Conductors (PVC enclosed) Powerail is compact, multiple conductor system with a self-insulation, non-corrosive housing. Powerail can be easily installed and is virtually maintenance free. Systems of 4 to 11 conductors with a capacity of 40 to 300 amps are available.
Recommended for: Cat. 4a, 4b & 4c |
 |
Trench Conductor Systems Trench conductor systems have load factor designed steel cover plates which are opened and closed by a lifting device as the crane moves. All VAHLE conductors can be installed in a trench system. Above-floor systems are available.
Recommended for: Cat. 5 |
 |
Cable Tenders Cable tenders are a continuous loop, bridge electrification system, especially suited for very high trolley traversing speeds and multiple conductor requirements. Cables or hoses can be installed.
Recommended for: Cat. 7 |
|
Cable Festoon Systems (small and medium size) Festoon systems support flat or round cables and hoses for hydraulic and pneumatic media to mobile equipment. All cable carriers comply with VDE and relevant international regulations. Low duty systems use C-rails or square bar tracks, medium duty systems run on I-beams. Cat. 8a, 8b, 8bF, 8bR, 8c |
|
Heavy duty and motor driven cable festoon systems VAHLE festoon systems support flat or round cables (power and control) and hoses for hydraulic and pneumatic media to mobile equipment. The cable carriers run on I-beam tracks. The equipment complies with VDE and relevant international regulations. For travel speeds exceeding 200 m/min. a range of motorized cable carriers is available. Cat. 8bF & 8bR |
|
Overload Protection Overload protection systems are used to avoid overloading of material handling equipment. Options with measuring amplifier and load displays are available. Cat. 9b |
 |
S M G - Data Communication System The SMG (Slotted Microwave Guide) is highly suitable for data communication up to 10 Mbps. Multi-channel function offers the possibility of simultaneous transmission of data, video, voice, and E-stop. Cat. 9e
Powercom® |
 |
C P S- Contactless Power System CPS represents a futuristic solution for non-contact current transmission to cranes, elevators, people movers, etc. High efficiency, no maintenance and consequently permant availability are only few of many benefits of the system. Cat. 9d |
|
Spring Driven Cable Reels Reels are used for automatic payout and winding of power/control cables or hoses to equipment in motion.
Recommended for: Cat. 9a |
 |
Motor Cable Reels Motor cable reels serve as power supply systems to track-guided consumers. They automatically payout or wind-on flexible cables for energy and control.
Recommended for: Cat. 10 |
